HUISN ZX45G universal vertical drilling and milling machine for metal gearhead milling well drilling machine for sale

HUISN ZX45G universal vertical drilling and milling machine for metal gearhead milling well drilling machine for sale

Item NO.: 20384952
TYPE
220v 380v
Accessories
Do not add DRO2axis DRO3axis pedestal Cooling system work light Knife Cutter
Inquiry

Detail | FAQ | Electronic Manual

  • Product NameHUISN ZX45G universal vertical drilling and milling machine for metal gearhead milling well drilling machine for sale
  • Item NO.20384952
  • Weight375.0000 kg = 826.7335 lb = 13227.7357 oz
  • CategoryMilling & Drilling Machine> ZX45G
  • BrandHUISN
  • Creation Time2022-10-26
  • Model Number:ZX45G
  • Brand Name:HUISN
  • Max Drilling Capacity:45 mm
  • Max Tapping Capacity:32mm
  • Max Face Milling surface Capacity:80 mm
  • Table Size:800*240mm
  • Spindle Tapet:MT4
  • Cross Travel (Y):200 mm
  • Longitudinal Travel (X):580 mm
  • Vertical Travel (Z):350 mm
  • Spindle Travel:130 mm
  • T Slot Size:3*16 mm
  • Range of Spindle Speed:80-1250 rpm
  • Swivel Angle of Milling Head:±90°
  • Number of Spindle Speeds:6
  • Distance From Spindle Axis to Column Surface:260 mm
  • Distance From Spindle to Table Surface:50-450 mm
  • Motor:1500W/ 220V/380V
  • Products Size:845*910*1020mm
  • N/W：325kg
  • G/W：375kg
  • Packing Size：900*960*1070 mm
  • Port:SHANGHAI/NINGBO
  • Customized logo(Min. order 5 pieces)
  • Customized packaging(Min. order 5 pieces)
  • Graphic customization(Min. order 5 pieces)
  • Lead time:1 piece=15days, >1 piece=To be negotiated
